7 1/16” 5M SHAFFER LXT
CATEGORY: BLOWOUT PREVENTERS – RAM STYLE, ANNULAR STYLE
7 1/16" 5M Shaffer LXT BOP
LKC Equipment supplies 7 1/16″ 5M Shaffer LXT BOP components and replacement parts for drilling, workover, completion, intervention, and pressure-control operations. The Shaffer LXT blowout preventer is designed to provide dependable well-control performance through hydraulic operation, robust sealing systems, and durable structural components.
Our inventory includes ram shaft seal assemblies, cylinders, pistons, manifold tubes, ram blocks, ram packers, top seals, molded door gaskets, hydraulic seals, seal kits, and replacement parts used to maintain and rebuild 7 1/16″ 5M Shaffer LXT BOP systems.
Parts:
| ITEM | PECO PN# | Description |
| 1 | 20021933 | Door |
| 2 | 20022087 | Cylinder |
| 3 | 20022086 | Piston Shaft |
| 4 | 20022088 | Locking Shaft |
| 5 | 20022653 | Manifold Tube |
| 6 | 20022084 | Cylinder Head |
| 7 | 20022103 | Molded Door Gasket |
| 8 | 1500390 | Male Nipple 3/8″ S.A.E. |
| 9 | 5019416 | O-Ring 3/8″ Quick Disconnect |
| 10 | 30928 | O Ring for Cylinder |
| 11 | 32008 | Back Up Ring For Cylinder |
| 12 | 20022403 | Seal F/ Cylinder Head |
| 13 | 32006 | Piston Seal |
| 14 | 185174 | Ram Shaft Seal Assembly |
| ‡ | 32004* | Hydrostatic Seal |
| ‡ | 32005* | Wiper Ring |
| ‡ | 32009* | Hydraulic Seal For Door |
| ‡ | 141365* | Spiral Retaining Ring |
| ‡ | 185172* | Wiper Ring Holder |
| ‡ | 185173* | Packing Adapter |
| 15 | 30653 | O-Ring for Manifold Tube |
| 16 | 20022704 | DU Bearing |
| 17 | 20009 | 7/8″ Hex Nut |
| 18 | 20022090 | Cylinder Stud |
| 19 | 65008 | Pipe Plug |
| 20 | 20020275 | Pipe Plug |
| 21 | 066502 | Pipe Plug |
| 22 | 8010201 | Hex Head Cap Screw |
| 23 | 20001174 | Flat Washer |
| 24 | 025046 | Lock Washer |
| 25 | 1500389 | Female Coupler 3/8″ S.A.E. |
| 26 | 20022085 | Support Bar |
| 27 | 20022650 | End Cap F/ Support Bar |
| 28 | 8002856 | Socket Head Cap Screw |
| 29 | 20022089 | Lock Bar |
| 30 | 20021470 | Hand Knob |
| ‡ | 20025967 | Pipe Plug |
| ‡ | 8130121 | Screw DRV |
| ‡ | 185181 | Handle (F/ Manual Operation) |
| ‡ | 20020261 | Slide Hammer |
| ‡ | 20021695 | Pin Assembly |
| ‡ | 20024693-1K | Seal Kit |
‡ ITEM NOT SHOWN
* ITEMS INCLUDED IN RAM SHAFT SEAL ASSEMBLY
RAM BLOCKS, PACKERS, TOP SEALS
DESCRIPTION | RAM BLOCKS | PACKERS |
STANDARD TOP SEAL |
| 722181 |
|
|
|
CSO | 722156 | 722183 |
1.315″ | 722157 | 722184 |
1.66″ | 722158 | 722185 |
1.90″ | 722159 | 722186 |
2 1/16″ | 722160 | 722187 |
2 3/8″ | 722161 | 722188 |
2 7/8″ | 722162 | 722189 |
3 1/2″ | 722163 | 722190 |
4″ | 722164 | 722191 |
4 1/2″ | 722165 | 722192 |
5″ | 722166 | 722193 |
5 1/2″ | 722167 | 722194 |
1.660″ OFFSET | 722296 | 722294 |
1.90″ OFFSET | 722301 | 722299 |
2 1/16″ OFFSET | 722306 | 722304 |
2 3/8″ OFFSET | 722311 | 722309 |
RAM BLOCKs
TOP SEALs
RAM PACKERs
Shaffer LXT BOP Components
The 7 1/16″ 5M Shaffer LXT BOP incorporates hydraulic, mechanical, and sealing assemblies engineered for dependable pressure-control performance.
Available components include:
- Doors
- Cylinders
- Piston Shafts
- Locking Shafts
- Manifold Tubes
- Cylinder Heads
- Support Bars
- End Caps
- Lock Bars
- Hand Knobs
These components work together to provide reliable operation and effective well control in demanding oilfield environments.
Ram Shaft Seal Assemblies
The ram shaft seal assembly is a critical component designed to maintain pressure integrity while allowing smooth ram movement.
Available ram shaft seal assembly components include:
- Ram Shaft Seal Assemblies
- Hydrostatic Seals
- Wiper Rings
- Hydraulic Seals
- Spiral Retaining Rings
- Wiper Ring Holders
- Packing Adapters
These sealing components help protect internal systems while maintaining dependable pressure-control performance.
Hydraulic Cylinder & Piston Components
The hydraulic operating system provides controlled ram actuation and pressure management.
Available hydraulic components include:
- Cylinders
- Piston Shafts
- Cylinder Head Seals
- Piston Seals
- Cylinder O-Rings
- Cylinder Backup Rings
- DU Bearings
- Cylinder Studs
- Hex Nuts
These components support efficient hydraulic operation and reliable well-control functionality.
Seal Kits & Replacement Seals
Hydraulic fluid delivery is essential to proper BOP operation.
Available components include:
- Manifold Tubes
- O-Rings for Manifold Tubes
- Male Nipples
- Female Couplers
- Pipe Plugs
- Quick Disconnect Components
- Hydraulic Connections
These products help maintain proper hydraulic flow and system integrity throughout operation.
Door & Structural Components
The Shaffer LXT utilizes a durable door assembly that houses and protects internal pressure-control components.
Available structural components include:
- Doors
- Molded Door Gaskets
- Support Bars
- End Caps
- Lock Bars
- Hand Knobs
- Cap Screws
- Flat Washers
- Lock Washers
These components contribute to equipment reliability and long-term service life.
Seal Kits & Replacement Seals
Maintaining seal integrity is critical for safe BOP operation.
Available sealing products include:
- Molded Door Gaskets
- Hydraulic Seals
- Hydrostatic Seals
- Piston Seals
- O-Rings
- Backup Rings
- Wiper Rings
- Packing Adapters
Complete Seal Kit Available: 20024693-1K Seal Kit
Ram Blocks & Ram Packers
LKC Equipment supplies ram blocks and ram packers for multiple tubular sizes used in Shaffer LXT BOP systems.
Available ram block and packer sizes include:
- CSO Rams
- 1.315″ Rams
- 1.66″ Rams
- 1.90″ Rams
- 2 1/16″ Rams
- 2 3/8″ Rams
- 2 7/8″ Rams
- 3 1/2″ Rams
- 4″ Rams
- 4 1/2″ Rams
- 5″ Rams
- 5 1/2″ Rams
Matching ram packers are available for each configuration.
Top Seals
Top seals are designed to provide dependable sealing performance between the ram assembly and BOP body.
Available product:
- Standard Top Seal
These components help maintain pressure integrity during drilling and intervention operations.
Offset Ram Packers
Offset ram packers are available for specialized pressure-control applications requiring offset sealing configurations.
Available offset packer sizes include:
- 1.660″ Offset
- 1.90″ Offset
- 2 1/16″ Offset
- 2 3/8″ Offset
These products provide additional operational flexibility for unique well-control requirements.
Manual Operation Components
The Shaffer LXT system also supports manual operation and servicing components.
Available products include:
- Manual Operation Handles
- Slide Hammers
- Pin Assemblies
- Lock Bars
- Hand Knobs
These components assist with maintenance, operation, and field servicing requirements.
Replacement Parts & Maintenance Components
LKC Equipment supplies replacement parts for maintaining and rebuilding Shaffer LXT BOP systems.
Available replacement components include:
- Support Bars
- End Caps
- Pipe Plugs
- Couplers
- Bearings
- Cylinder Components
- Locking Shafts
- Hydraulic Components
- Seal Assemblies
- Structural Hardware
These components help reduce downtime and support preventative maintenance programs.
Applications
7 1/16″ 5M Shaffer LXT BOP components are commonly used in:
- Drilling operations
- Well control systems
- Pressure-control equipment
- Workover operations
- Completion activities
- Intervention services
- Oilfield maintenance programs
These components help operators maintain safe and reliable pressure-control performance in demanding oilfield environments.
Why Choose LKC Equipment
LKC Equipment supplies quality pressure-control equipment and replacement components for oilfield operations worldwide.
Benefits include:
- Shaffer LXT BOP components
- Ram shaft seal assemblies
- Hydraulic cylinders and piston shafts
- Ram blocks and ram packers
- Top seals and offset packers
- Complete seal kits
- Hydraulic connection components
- Industry-proven pressure-control equipment
Frequently Asked Questions
The Shaffer LXT is a ram-type blowout preventer designed for well-control and pressure-containment applications in drilling and intervention operations.
These components are designed for 7 1/16″ 5M Shaffer LXT BOP systems.
Yes. Ram blocks and matching ram packers are available from CSO through 5 1/2″ pipe sizes.
The ram shaft seal assembly includes hydrostatic seals, hydraulic seals, wiper rings, packing adapters, retaining rings, and related sealing components.
Yes. Offset ram packers are available in 1.660″, 1.90″, 2 1/16″, and 2 3/8″ configurations.
Yes. Complete seal kits, molded door gaskets, hydraulic seals, piston seals, O-rings, and backup rings are available for Shaffer LXT BOP systems.
Request a Quote from a Trusted Oilfield Equipment Supplier
Looking for 7 1/16″ 5M Shaffer LXT BOP components, ram blocks, ram packers, top seals, hydraulic cylinders, ram shaft seal assemblies, seal kits, or replacement parts?
Contact LKC Equipment today for oilfield equipment, oil and gas tools, equipment availability, specifications, and pricing. Our team can help identify the correct Shaffer LXT pressure-control components for your drilling, workover, and well-control requirements. We supply new, used, and refurbished well control equipment for drilling, workover, and oilfield operations. Our team is ready to support your operations with reliable supply and fast service.
Our commitment to quality and reliability has positioned us as a trusted oilfield equipment supplier and oilfield supply company serving clients across Oklahoma, North Dakota, Pennsylvania, California, and Texas, and across the United States and worldwide.
